Cube shelving · 49 × 41 × 61 cm
Nomad
29,600 ₽
Pre-order: production from 45 working days
Colour · black, colour flecks
Cube modules cut from sheet on steel posts: the cubes hang on mini posts with collars and are open at the front and back — for records, books, boxes. Columns and tiers are tied together by shared rods.
- Overall size, W × D × H
- 486 × 406 × 608 mm
- Weight
- ≈ 15.7 kg
- Material
- rPS 12 mm · black, colour flecks
- Frame
- rods Ø10 mm, hardened chrome-plated steel
- Castors
- swivel Ø50, two with brakes
- Assembly
- with the keys from the box, by the instructions
Drawing
Front, side and plan views with dimensions. Click the sheet for a closer look. The file is an A3 sheet: print it at 100% and the scale is true.
What’s in the box
- Sheet parts
- cube base / top — 2, cube side — 2
- Rods Ø10
- 18 pcs, 8.0 m, cut to length
- T-clamps
- 4 pcs
- Castors Ø50
- 4 pcs
- Cross clamps
- 28 pcs
- Stop collars
- 8 pcs
- Hex key set
- 1 pc
- Assembly instructions
- step by step, illustrated
Need a different size?
Build your own version in the configurator: size to the millimetre, colour, castors — with an instant price.
